Capacity

Cut 40 test strip substrates per minute

(Using production capacity of 30-38 pieces / minute) Continuous production for 30 minutes without stopping, the cutting quantity reaches 1200 pieces / 30 minutes.

Unscramble

Automatic bottle sorting

Ranch

Feeding

Manual feeding of 400 tablets / time, automatic film feeding, with abnormal recognition and alarm function. Manual loading, should be stable when feeding 200 tablets. With out-of-material reminder and no-material shutdown alarm function, 40 pieces can be delivered per minute.

Cutting quality

The cutting appearance quality meets the requirements of the relevant product inspection standard standards. There are no appearance quality problems such as burrs, indentations, leaks, splits, chipping, and bending.

Scrap function

The rejection rate of waste strips is 100%. The rejection rate of waste edges is 100%. All the waste edges should be stored. The period of manual cleaning is more than two hours.

Defective waste strips should be identified, and the test strips cut this time should be stored separately and not damaged for continued use.

The rejection behavior shall not interrupt the operation and shall not affect the correctness of filling.

Filling function

1. The success rate is 100%. Do not damage the test strips or missing strips during the loading process.

2. Reserve the detection interface. 1. Continuously check the qualified rate of 10,000 bottles at 100%.

Molecular sieve function

Can achieve automatic loading of molecular sieve, 100% success rate

The molecular sieve was successfully installed without damage to the product, and the success rate was 100%.

Cutter

1. The service life of each set of tools is 2 years, and the maintenance period is longer than 6 months. Equipped with automatic cleaning tool function for easy cleaning.

Dust control

Measures to prevent dust from escaping and sticking into the can

Count

Safety requirements Equipped with corresponding safety devices to prevent operators from contacting the rotating device and cutters, there are protective devices.

Speed ​​regulation function, can feed test paper tube into capping machine

Can be fully automatic capping, aluminum foil sealing, and other functions.
